Welding machine Cable

Black welding machine cable coiled in a loop with insulated thick wire and metal connector ends for welding machines
Welding machine Cable - Image 2

Welding machine Cable

₹220.00

Technical Specifications / Dimensions:

  • Conductor: 99.9% Pure Copper
  • Cable Type: Flexible Multi-Strand Welding Cable
  • Insulation: EPDM / PVC Heat-Resistant
  • Voltage Rating: 450V – 600V
  • Temperature Resistance: 90°C – 150°C
  • Applications: Electrode holder cable, Earthing cable, Machine cable

Most Demanded Running Sizes in India

Cable Size (sqmm) Amp Capacity Common Usage
10 sq mm 100–150A Light welding work
16 sq mm 150–200A Small workshops
25 sq mm 200–250A Medium fabrication
35 sq mm 250–300A Industrial welding
50 sq mm 300–400A Heavy-duty welding
70 sq mm 400–500A Continuous industrial load
Category: Tags: , , , , ,

Description

Welding Machine Cable (also known as welding lead cable) is a high-flexibility, heat-resistant, and heavy-duty copper cable used to supply stable current from a welding machine to the electrode holder or earth clamp. Designed for rugged industrial use, this cable ensures consistent power flow, minimal voltage drop, and safe operation during welding.

Manufactured with 99.9% pure copper strands, these cables provide high conductivity and excellent flexibility for easy handling in workshops, construction sites, and fabrication units. The outer sheath is made from EPDM rubber or PVC, offering resistance against heat, oil, cuts, abrasion, and sparks. Suitable for ARC, MIG, TIG, and inverter welding machines.

Key Features

  • High Conductivity Copper Wire for smooth current flow
  • Flexible Multistrand Design for easy movement during welding
  • Heat & Flame Resistant Outer Jacket (EPDM/PVC)
  • Durable, Crack-Resistant & Abrasion-Proof
  • Low Power Loss & Voltage Drop even in long usage
  • Safe for heavy-duty industrial welding
  • Compatible with all ARC/MIG/TIG welding machines
  • Ideal for electrode holders, earth clamps & power connections

Welding Cable Insulated 35, 50,  70 Sqmm per meter

Additional information

Sq Mm

35 Sq/mm, 50 Sq/mm, 70 Sq/mm
